TIME – adjust the delay time from 10ms to 900ms.
REPEAT – controls the feedback of the delay.
MOD – Adds a luscious modulation to the delay. At 12 o’clock there is no modulation. Clockwise adds a slow chorus and counter-clockwise adds a fast vibrato.
MIX – Controls the blend between fully dry (clean) and fully wet (repeat only) echo sound. 12 o’clock is an equal mix of clean and echo. *Hint: The Mod knob works even when the delay time turned all the way down, allowing the Amnesia to function as an analog-flavored chorus pedal. Mode Toggle: MN3005 – Warm repeats with excellent fidelity and mild “bucket loss” where each of the delay repeats becomes a bit softer and more diffuse.
SAD4096 – A very distinct tone where longer delay times have a pronounced distortion character. [This mode will sound like a spaceship a bit sooner than the others.]
MN3208 – Audibly darker tone with soft and super murky repeats. Perfect for ambient pads and washes if you use your volume knob right. The Amnesia requires a 9V DC power supply with a 2.1mm pin, center negative. The Amnesia is not designed to be powered on supplies higher than 9V and does not use a battery. The Amnesia should work fine on a multi-pedal "daisy chain" connector, but if you encounter excessive noise or hum try a separate power supply. The Amnesia requires approx. 60mA.
