Description
Specifications
Power Output: |
0 to 50 watts maximum, 4-8 ohms |
AC Power Req.: |
100–240Vac, 50–60 Hz, 100 W maximum |
Input Connections: |
¼" mono, 2M input impedance, 2V peak |
Effects Send: |
¼” mono, 1V full scale, 600 ohms |
Effects Return: |
¼” mono, 1V full scale, 47K |
Headphone Output: |
1/4" jack, 4V peak |
Speaker 1 Output: |
8 ohms, 60-100 W recommended rating |
Speaker 2 Output: |
4 ohms, 60-100 W recommended rating |
Dual Speakers 1+2 |
8 ohms each, 30-50W recommended rating. |
H x W x D |
8.5”(218mm) x 7.5” (190mm) x 3” (76mm) |
Weight |
2 lbs (0.9kg) |
