Description
Nominal Input Level-20 dBuInput
Impedance1 M ohm
Nominal Output Level-20 dBu
Output Impedance1 k ohm
Recommended Load Impedance10 k ohms or greater
Maximum Recording TimeApproximately 12 minutes
ControlsPedal switch
LEVEL knobIndicatorsCHECK indicator
LOOP indicatorConnectorsINPUT A (MONO) jack: 1/4-inch phone type
INPUT B jack: 1/4-inch phone type
OUTPUT A (MONO) jack: 1/4-inch phone type
OUTPUT B jack: 1/4-inch phone type
STOP/UNDO jack: 1/4-inch TRS phone type
DC IN jackPower SupplyAlkaline battery (9 V, 6LR61)
AC adaptor (sold separately)
* Rechargeable Ni-MH batteries cannot be used.
